FZ32 Stainless Steel Sintered Powder Metallurgy Bearing and Components

Standard: Soperb Oilites
Code: FZ32
Type: Stainless Steel Base
Applications: Bearings or Mechanism Parts
Product description: The FZ32 is a SS316 stainless steel sintered powder metallurgy bearing and component, oil-impregnated to provide corrosion-resistant self-lubrication. Perfect for HVAC systems and home appliances, it
INQUIRY

FZ32 Stainless Steel Base (High-Cr) Sintered Bearing Material

FZ32 is a high-density stainless steel base, oil-impregnated sintered self-lubricating bearing material per Soperb Oilites standard. Higher density provides superior load capacity and wear resistance while maintaining excellent corrosion resistance. Suitable for demanding applications in chemical processing, offshore, and food industry equipment.

Chemical Composition (Soperb Oilites / ISO 2795 (DIN 1850 Part 3))

Element	Content
Fe	Balance
Cr	16.0~18.0%
Ni	10.0~14.0%
Mo	2.0~3.0%
C	≤0.08%

Mechanical & Physical Properties

Property	Value
Oil Retaining	10%~15%
Radial Crushing Strength	≥220 MPa
Max. Linear Speed	5 m/s
Max. PV	10 N/mm² · m/s
Hardness	HB 70~100

Products Standard: ISO 2795 (DIN 1850 Part 3). Radial crushing strength values are shown at corresponding oil retaining levels — higher oil content reduces crushing strength. All materials are oil-impregnated via vacuum soaking process.
